hot air generator, workshop heater, hall heater
Fabbri
Heating
Type:
F28 c.v.
Good to know:
CE Marking, hot air fan, smoke fan
Technische Daten:
- flue capacity: 34 kW
- Conventional yeld capacity: 29 kW
- flue diameter: 160 mm
- hot air delivery pipes: 2 x 180 mm
- flue length: 500 mm
- oven width: 400 mm
- oven hight: 590 mm
- air flow: 2200 m³/h
- power consumption: 400 W
- aproximate surface to heat up: 500 m³
- area to be heated: 100/150 m²
- heater height without hot air conveying pipes: 1560 mm
- heater width : 550 mm
- heater lenght: 920 mm
- weight: 190 kg
- Model year: 2024
- Location: not at stock
Horizontal oven made of thermal chrome plated stainless steel, reinforced with ribs.
Exchangers 2 or 3 smoke revs.
Inner side made of bright sheet metal for casing and insulation.
Outer side made of zinc plated sheet metal.
Frame made of painted profile.
Feeding doors with refractory and extractable grates.
Panels with refractory for pipes cleaning.
Double suction centrifugal fans for hot air delivery running at low regime of turns and arranged on special elastic suspensions driven by one or more electric motors.
Smoke extraction fan (except mod. F 28-F 55 sv - F 85 sv).
Electric command and control panel - adjusting thermostat. marking
Exchangers 2 or 3 smoke revs.
Inner side made of bright sheet metal for casing and insulation.
Outer side made of zinc plated sheet metal.
Frame made of painted profile.
Feeding doors with refractory and extractable grates.
Panels with refractory for pipes cleaning.
Double suction centrifugal fans for hot air delivery running at low regime of turns and arranged on special elastic suspensions driven by one or more electric motors.
Smoke extraction fan (except mod. F 28-F 55 sv - F 85 sv).
Electric command and control panel - adjusting thermostat. marking
